School Bus

BharatBenz School is all about a delightful ride to school.  Built with the finest blend of engineering and technology, these buses are based on a sturdy high-grade tubular structure, delivering a safer trip for the passengers. Plus, the vinyl flooring on the bus is furnished with an anti-skid top layer, helping children travel around the bus safely. The bus also features strategically placed emergency exits for quicker evacuation.

  • Model : 4D34i
  • Power : 170HP (125kW) @ 2500rpm
  • Torque : 520Nm @ 1500rpm
  • No of Cylinders, Displacement CC : 4 Cylinder, 3907cc


Comfortable SeatsBharatBenz school bus new milestone in comfort and convenience. Every seat in our buses is a cocoon of comfort, designed to give a comfortable ride to school and back home. BharatBenz school buses are loaded with features that completely fulfills the childrens needs.
SuspensionMeticulously designed Parabolic suspension system with integrated fine tuned shock absorber and anti-roll bar is ensures the best in class riding comfort

Longer Service IntervalsBest in class reliability with optimized service intervals for engine, transmission, axle and corrosion preventive body ensures the lowest maintenance.
Better HandlingThe wide chassis frame width and tubeless radial tyres enhance the stability of the vehicle, while the front and rear anti-roll bars result in improved cornering, better handling of the bus.

General characteristics:4 Cylinder, Vertical in-line BSVI, inter-cooled, turbo-charged
Engine Capacity:3907cc
Engine Max output:170HP (125kW) @ 2500rpm
Engine Max torque: 520Nm @ 1500rpm
Gearbox Model:M036, Synchromesh
No. of Gears:6 forward with overdrive+1 reverse
Clutch Type: Organic, Single dry plate, ⌀ 325mm
Brake Type:Dual Circuit, full air S-Cam type drum
Auxiliary Brake: Exhaust brake
Electronic Brake: Anti-lock Braking System (ABS)
Front Axle:Heavy-duty reverse elliot 'I' beam
Rear Axle:Fully floating type
Suspension Type:Parabolic suspension at front and rear
Anti roll bars:Double acting telescopic shock absorber and anti roll bars at front and rear
Steering Type: Power steering, adjustable and tiltable
Tyre Type: 235/75 R 17.5 tubeless tyres
Battery:2x12V, 120Ah
Fuel Tank/Filling Capacity:171L/160L
Adblue Tank/Filling Capacity:43L/36L
Seats:Bench type seats with under seat luggage racks, chin guards, handholds and aisle side hold
Seat Layout/capacity:3 x 2 layouts with 49 bench type seats (Option - 2x2 layout with 39 HHR seats)
Floor:Marine grade plywood, Anti-skid vinyl top layer
Passenger door:In-swing, Automatic
Windows: Fixed glass
Emergency exit: Door at rear RHS, rear breakable glass, all windows breakable
Emergency kit: Fire extinguisher (5kg x2 ), First-Aid kit
Hatrack: Hat rack with Free Flow vents (Option – Modular Hat rack)
Lights: 4+1 standard LED lights with integrated night lamp distributed through saloon area
Safety features: Seat belts, provision for CCTV, GPS, RFID and navigator, retractable first step, door opening alarm, guarded driver area, emergency alarm, stop sign
Fitments:Notice Board
